Journal of Software Engineering and Applications, 2011, 4, 388-390

doi:10.4236/jsea.2011.46044 Published Online June 2011 (http://www.SciRP.org/journal/jsea)

Prediction of Outcome in the Vegetative State by

Machine Learning Algorithms: A Model for

Clinicians?

Loris Pignolo1*, Vincenzo Lagani2

1S. Anna Rehabilitation Institute and RAN-Research on Advanced Neuro-rehabilitation, Crotone, Italy; 2Biomedical Laboratory,

Institute of Computer Science, Foundation for Research and Techno l ogy-Hellas, Heraklion, Greece.

Email: [email protected], [email protected]

Received June 8th, 2010; revised March 13th, 2011; accepted April 20th, 2011.

ABSTRACT

Purpose of this study was to compare different Machine Learning classifiers (C4.5, Support Vector Machine, Naive

Bayes, K-NN) in the early prediction of outcome of the subjects in vegetative state due to traumatic brain injury. Accu-

racy proved acceptable for all compared methods (AUC > 0.8), but sensitivity and specificity varied considerably and

only some classifiers (in particular, Supp ort Vector Machine) appear applicable models in the clinical routine. A com-

bined use of classifiers is advisable.

Keywords: Artificial Intelligence, Vegetative State, Clinical Outcome, Prognosis

1. Introduction

Vegetative state (VS) is a clinical condition resulting

from severe brain damage and characterized by the lack

of awareness (of self and environment), voluntary or

otherwise purposeful behavioral responses, and commu-

nication in patients [1-6]. The early prediction of out-

come has high priority for both the patient’s family and

attending physicians, who need to plan dedication and

resources [7-9]. However, no prognostic model has yet

proved suitable of generalization across different set-

tings. Neither the traditional or newly developed elec-

trophysiological techniques (waking and sleep EEG,

visual auditory or somatosensory evoked potentials,

event-related potentials, EEG brain imaging) nor other

methods of functional evaluation (fMRI) are usable

prognostic tools. An empirical prognostic model has

been developed based on the appearance/disappearance

and timing of observation of conventional neurological

signs [10,11] and made available to clinicians. Eye

tracking (i.e. smooth eye pursuit of moving target),

spontaneous motility, the oculocephalic reflex and the

chewing/sucking reflex were the relevant signs ac-

cording to the model developed by data mining algo-

rithms, with greater accuracy of prediction in post-

traumatic subjects in VS. Prognosis nevertheless de-

pended on evolution over time rather than on early as-

sessment.

Purpose of this study is to assess the efficacy of

theavailable decisional models in comparison with

those suitable of application in this context. To this end ,

a subpopulation of subjects in VS due to head trauma

was studied at admittance to the dedicated unit for VS

of the Institute S. Anna – RAN.

2. Methods

Two hundreds forty one patients admitted to the dedi-

cated semi-intensive care over an 11-year period (April

1998 - June 2009) were considered retrospectively. In-

clusion criteria were posttraumatic aetiology and a diag-

nosis of vegetative state, as clinically defined compliant

to the criteria suggested by the Multi-Society Task Force

and the guidelines of the London Consensus Conference

[5,12]. Patients recovering consciousness within 4 weeks

from brain injury, with severe spinal fractures spinal cord

damage or otherwise requiring intensive treatment or sur-

gery, or in VS resulting from alcohol or drug overdose,

or with a Glasgow Coma Scale [13] rating > 8 at admis-

sion were excluded in order to minimize misdiagnoses.

For each patient the following parameters were col-

lected: age, sex, days in hospital reanimation unit, Gas-

cow Coma Scale at admission, necessity of tracheotomy,

necessity of nasogastric feeding tube (NFT), need of per-

Prediction of Outcome in the Vegetative State by Machine Learning Algorithms: A Model for Clinicians?389

cutaneous endoscopic gastronomy (PEG), presence of

dysautonomic syndrome. The presence of preselected

neurological signs (spontaneous motility, chewing and

sucking reflexes, oculo-cephalic reflex, eye tracking) was

searched for at admission. The outcome were assessed by

the Glasgow Outcome Scale (GOS) [14]; patients were

allocated to two main clusters of classes, i.e. to negative

(GOS 1 or 2) or positive (GOS score 3 to 5) outcome.

All the numerical variables were normalized in the in-

terval (0,1). Four different machine learning methods

were used for data analysis: K Nearest Neighbours

(K-NN) [15], Naïve Bayes [16], C4.5 Decision Tree

[17,18], Support Vector Machine (SVM) [19]. The se-

lected algorithms follow distinct approaches in model

development. A major methodological issue was to

compare the suitability of a decision tree rule-based ap-

proach (C4.5), Bayesian methods or numerical algo-

rithms (SVM, K-NN ) [2 0].

These algorithms require the “a priori” specification of

one or more parameters [21]. We used a repeated cross

validation procedure to evaluate the results of each pa-

rameter configuration and avoid over-fitting. Cross vali-

dation is an established technique for the assessment of

the generalizability of the result of a statistical analysis

[22]. It partitions the dataset in several complementary

folds, to then use each fold as test-set, while the remain-

ing dataset is used to build a model/execute the analysis.

The results of the different test-sets are then averaged.

The repetition of dataset splitting guarantees the results

independence from the actual dataset subdivision [23].

As a further step, we used the Area Under the Curve

(AUC) [24,25] metrics to identify the best configuration

of parameters for each machine learning algorithm. AUC

values can range from 0 (total misclassification) to 1

(perfect classification); random classification is arounf

0.5. AUC has the advantage of independency from distri-

bution, i.e. evaluation of the results is not biase in over-

represented classes. In addition, we estimated for each

algorithm the sensitivity and specificity for positive out-

come [26]. All the experiments were performed making

use of the WEKA (Waikato Environment for Knowledge

Analysis) software [27,28].

3. Results and Discussion

AUC values indicate good classification performances

for all the used classifiers; however, the sensitivity and

specificity estimates outline differences among the used

statistical methods (Tables 1 and 2). Sensitivity was al-

ways higher than specificity, therefore indicating that the

methods detect positive outcomes more easily (i.e. posi-

tive outcome can be excluded for patients classified as

candidates to a negative outcome; on the contrary, low

specificity does not exclude a negative prognosis for pa-

Table 1. AUC for each dataset and algorithm.

AUC

C4.5 0.84

SVM 0.81

Naive Bayes 0.91

K-NN 0.88

Table 2. Sensitivity and specificity for class “positive out-

com e” (GOS values 3, 4 and 5).

sensitivity specificity

C4.5 0.94 0.58

SVM 0.97 0.65

Naive Bayes 0.83 0.77

K-NN 0.97 0.44

tients whose outcome was classified as positive); high

sensitivity of the machine learning model is therefore a

prerequisite in the early identification of patients with

positive prognosis. In this respect, SVM seems to be the

most suitable models for performing differential prog-

nostic evaluations. On the contrary, Naïve Bayes sensi-

tivity and specificity values are similar, indicating that

such models can identify both the positive and negative

outcomes with acceptable accuracy. C4.5 and K-NN

methods proved Pareto dominated [29] by the other two

algorithms.

4. Conclusions

We compared four different machine learning methods

(C4.5, SVM, Naïve Bayes and K-NN) to identify the

most suitable algorithm in the prognostic evaluation of

subjects in vegetative state. All the tested algorithms are

usable in this respect. SVM can be used for differential

prognostic evaluations, i.e. SVM models may be a useful

clinical tool to exclude a positive outcome. K-NN and

C4.5 could be used for the same purpose, but their sensi-

tivity and specificity are inferior to SVM. The Naïve

Bayes classifiers do not appear usable for differential

prognosis, due to poor efficiency in recognizing a spe-

cific class of subjects, but have limited classification er-

rors and can be still considered as a valid (ancillary)

prognostic tool. A decision to use classifiers specialized

in differential prognosis or predictiv e models able to g ive

reasonably accurate evaluation for both classes would

depend on the clinical rationale and applied protocols. It

may be worth noting that C4.5 remains a tool with poten-

tial clinical application in spite of poor performances; it

is the only algorithm among those studied to be able to

provide graphical models user-friendly to the clinician.

The ccombined use of different machine learning tools

may be preferable in the vegetative state clinical setting,

Prediction of Outcome in the Vegetative State by Machine Learning Algorithms: A Model for Clinicians?

390

with the approach complexity predictably compensated

for by the overall resources that the care of patients in

vegetative state requires.

REFERENCES

[1] B. Jennett and F. Plum, “Persistent Vegetative State after

Brain Damage: A Syndrome in Search of a Name,” Lan-

cet, Vol. 1, 1972, pp. 734-619.

doi:10.1016/S0140-6736(72)90242-5

[2] G. Dolce and L. Sazbon, “The Posttraumatic Vegetative

state,” Stuttgart, Thiene, 2002.

[3] S. Laureys, “The Neural Correlate of (un) Awareness:

Lessons from the Vegetative State,” Trends in Cognitive

Sciences, Vol. 9, No. 12, 2005, pp. 556-559.

doi:10.1016/j.tics.2005.10.010

[4] B. Jennett, “The Vegetative State,” Cambridge University

Press, Cambridge, 2002.

doi:10.1017/CBO9780511545535

[5] Multi-Society Task Force on PVS, “Statement on Medi-

cal Aspects of the Persistent Vegetative State,” The New

England Journal of Medicine, Vol. 330, No. 21, 1994, pp.

1499-1508. doi:10.1056/NEJM199405263302107

[6] A. Zeman, “Consciousness,” Brain, Vol. 124, 2001, pp.

1263-1289.

[7] R. Braakman, W. B. Jennett and J. M. Minderhoud,

“Prognosis of the Post Traumatic Vegetative State,” Acta

Neurologica Scandinavica, Vol. 95, 1988, pp. 49-52.

doi:10.1007/BF01793082

[8] E. Schmutzard, A. Kampfl, G. Franz, B. Pfausler, H. P.

Haring, H. Ulmer, S. Felber, S. Golaszewski and F.

Aichner, “Prediction of Recovery from Post Traumatic

Vegetative State with Cerebral Magnetic-Resonance Im-

aging,” Lancet, Vol. 351, No. 9118, 1998, pp. 1663-1671.

[9] A. Rovlias and S. Kotsou, “Classification and Regression

Tree for Prediction of Outcome after Severe Head Injury

Using Simple Clinical and Laboratory Variables,” Jour-

nal of Neurotrauma, Vol. 21, 2004, pp. 886-893.

doi:10.1089/0897715041526249

[10] G. Dolce, M. Quintieri, S. Serra, V. Lagani and L.

Pignolo, “Clinical Signs and Early Prognosis: A Deci-

sional Tree, Data Mining Study,” Brain Injury, Vol. 22,

No. 7-8, 2008, pp. 617-623.

doi:10.1080/02699050802132503

[11] L. Pignolo, M. Quintieri and W. G. Sannita, “The Glas-

gow Outcome Scale in Vegetative State: A Possible

Source of Bias,” Brain Injury, Vol. 23, No. 1, 2009, pp.

1-2. doi:10.1080/02699050802595873

[12] K. Andrews (Chairman), “International Working Party

Report on the Vegetative State,” Royal Hospital for

Neuro-Disability, 1996.

http://www.comarecovery.org/s.htm

[13] G. Teasdale and B. Jennet, “Assessment of Coma and

Impaired Consciousness: A Practical Scale,” Lancet, Vol.

2, 1974, pp. 81-84.doi:10.1016/S0140-6736(74)91639-0

[14] B. Jennet and M. Bond, “Assessment Outcome after Se-

vere Brain Damage: A Practical Scale,” Lancet, Vol. 1,

1976, pp. 480-484.

[15] G. Shakhnarovish, T. Darrell and P. Indyk, “Near-

est-Neighbor Methods in Learning and Vision,” The MIT

Press, Cambridge, 2005.

[16] P. Domingos and M. Pazzani, “On the Optimality of the

Simple Bayesian Classifier under Zero-One Loss,” Ma-

chine Learning, Vol. 29, 1997, pp. 103-137.

doi:10.1023/A:1007413511361

[17] J. R. Quinlan, “C4.5: Programs for Machine Learning,”

Morgan Kaufmann Publishers, Waltham, 1993.

[18] L. Breiman, J. H. Friedman and R. A. Olshen, “Classifi-

cation and Regression Trees,” Wadsworth International,

Belmont, CA, 1984.

[19] N. Cristianini and J. Shawe-Taylor, “An Introduction to

Support Vector Machines and Other Kernel-Based

Learning Methods,” Cambridge University Press, Cam-

bridge, 2000.

[20] R. C. Holte, “Very Simple Classification Rules Perform

Well on Most Commonly Used Datasets,” Machine

Learning, Vol. 11, No. 1, 1993, pp. 63-90.

doi:10.1023/A:1022631118932

[21] F. Moser, G. E. Rong and E. Martin, “Joint Cluster

Analysis of Attribute and Relationship Data without Ap-

riori Specification of the Number of Clusters,” In Pro-

ceedings of the 13th ACM SIGKDD International Con-

ference on Know- ledge Discovery and Data Mining, San

Jose, California, 12-15 August 2007.

[22] M. Stone, “Cross-Validatory Choice and Assessment of

Statistical Predictions,” Journal of the Royal Statistical

Society, Vol. 36, No. 2, 1974, pp. 111-147.

[23] R. Picard and D. Cook, “Cross-Validation of Regression

Models,” Journal of the American Statistical Association,

Vol. 79, No. 387, 1984, pp. 575-583.

doi:10.2307/2288403

[24] M. L. Thompson and W. Zucchini, “On the Statistical

Analysis of ROC Curves,” Statistics in Medicine, Vol. 8,

No. 10, 1989, pp. 1277-1290.

doi:10.1002/sim.4780081011

[25] M. S, Pepe, “A Regression Modelling Framework for

ROC Curves in Medical Diagnostic Testing,” Biometrika,

Vol. 84, 1998, pp. 595-608.

[26] R. W. Thatcher, R. A. Walker, C. J. Biver, D. M. North

and R. Curtin, “Sensitivity and Specificity of an EEG

Normative Database: Validation and Clinical Correla-

tion,” Journal of Neurotherapy, Vol. 7, No. 3-4, 2003, pp.

87-121. doi:10.1300/J184v07n03_05

[27] E. Frank, “Machine Learning with WEKA,” University of

Waikato, New Zealand, 1999.

http://www.cs.columbia.edu/~jaxin/nlpmeetings/2004-04-

22-lokesh.ppt

http://ww w.cs.waikato.ac.nz/ml/weka

[28] J. H. Van Bemmel and M. A. Munsen, “Handbook of

Medical Informatics,” Springer-Verlag, Berlin, 1997.

[29] M. J. Osborne and A. Rubenstein, “A Course in Game

Theory,” MIT Press, Cambridge, 1994.
